Pointwork Components -Aluminium 21mm High Rail

Cast Aluminium Crossing Units

Can be used for other rail heights with use of packing plates

1-2.5 to suit 21mm high rail 5" or 7 1/4" gauge Length 110mm - Cast Aluminium
Part No: S8125
Unit Price inc. VAT £19.50 EACH

1-3 to suit 21mm highrail 5" or 7 1/4" gauge Length 140mm - Cast Aluminium
Part No: S8130
Unit Price inc. VAT £22.00 EACH

1-3.5 to suit 21mm high rail 5" or 7 1/4" gauge Length 150mm - Cast Aluminium
Part No: S8135
Unit Price inc. VAT £24.00 EACH

1-4 to suit 21mm high rail 5" or 7 1/4" gauge Length 165mm - Cast Aluminium
Part No: S8140
Unit Price inc. VAT £26.00 EACH

1-5 to suit 21mm high rail 5" or 7 1/4" gauge Length 205mm - Cast Aluminium
Part No: S8150
Unit Price inc. VAT £27.50 EACH

1-6 to suit 21mm high rail 5" or 7 1/4" gauge Length 240mm - Cast Aluminium
Part No: S8160
Unit Price inc. VAT £29.50 EACH

1-7 to suit 21mm high rail 5" or 7 1/4" gauge Length 280mm - Cast Aluminium
Part No: S8170
Unit Price inc. VAT £35.00 EACH

1-8 to suit 21mm high rail 5" or 7 1/4" gauge Length 295mm - Cast Aluminium
Part No: S8180
Unit Price inc. VAT £37.00 EACH

Pairs of Standard Left/Right Hand Point Blades

in Aluminium 21mm high flat-bottomed rail

Supplied curved to suit hand required

10ft to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 315mm
Part No: S7511
Unit Price inc. VAT £40.00 Per Pair

15ft to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 386mm
Part No: S7513
Unit Price inc. VAT £44.50 Per Pair

20ft to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 445mm
Part No: S7514
Unit Price inc. VAT £52.00 Per Pair

30ft to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 544mm
Part No: S7515
Unit Price inc. VAT £59.50 Per Pair

45ft to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 668mm
Part No: S7517
Unit Price inc. VAT £62.00 Per Pair

60ft to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 770mm
Part No: S7519
Unit Price inc. VAT £70.00 Per Pair

80ft to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 889mm
Part No: S7520
Unit Price inc. VAT £79.50 Per Pair

Pairs of Symmetrical Wye Point Blades

in Aluminium 21mm high flat-bottomed rail

10ft Symmetrical Wye to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 223mm
Part No: S7611
Unit Price inc. VAT £39.00 Per Pair

15ft Symmetrical Wye to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 272mm
Part No: S7612
Unit Price inc. VAT £40.00 Per Pair

20ft Symmetrical Wye to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 315mm
Part No: S7511Y
Unit Price inc. VAT £45.00 Per Pair

30ft Symmetrical Wye to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 386mm
Part No: S7513Y
Unit Price inc. VAT £52.00 Per Pair

40ft Symmetrical Wye to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 445mm
Part No: S7514Y
Unit Price inc. VAT £52.00 Per Pair

60ft Symmetrical Wye to suit 21mm high rail 5" or 7 1/4" gauge - Overall Length 544mm
Part No: S7515Y
Unit Price inc. VAT £59.50 Per Pair

Point Fittings - 5" gauge

To suit 21mm high Aluminium rail

Tie Bar Sets - Stainless Steel

To suit 21mm high Aluminium rail - 5" gauge.

5"g Tie Bar Set - Stainless Steel. To suit 21mm high rail.
Part No: 21MM05TB
Unit Price inc. VAT £

Stock Rail Stand Up Bracket & Blade Slide Plate Sets - Stainless Steel

To suit 21mm high Aluminium rail - 5" gauge.

For 25mm x 25mm (or larger) sleepering

One set shown in each photograph

5"g Set of stock rail Stand Up Brackets /Slide Plates S Steel. For 21mm high rail & 4.8mm dia rail screw.
Part No: 21MM05SB+SP
Unit Price inc. VAT £

Blade Tip Slide Plate - Pair - Stainless Steel

To suit 21mm high Aluminium rail - 5" gauge.

For 25mm x 25mm(or larger) sleepering

5"g. Pair of Blade Tip Plates - Stainless Steel. For 21mm high rail / 4.8mm dia rail screw.
Part No: 21MM05BTP
Unit Price inc. VAT £

Point Fittings - 7 1/4" gauge

To suit 21mm high Aluminium rail

Tie Bar Sets - Stainless Steel

To suit 21mm high Aluminium rail - 7 1/4" gauge.

7 1/4"g Tie Bar Set - Stainless Steel. To suit 21mm high rail.
Part No: 21MM07TB
Unit Price inc. VAT £

Stock Rail Stand Up Bracket & Blade Slide Plate Sets - Stainless Steel

To suit 21mm high Aluminium rail - 7 1/4"

For 50mm wide x 25mm deep (or larger) sleepering

One set shown in each photograph

7 1/4"g Set of stock rail Stand Up Brackets /Slide Plates S Steel. For 21mm high rail / 6.3mm dia rail screw.
Part No: 21MM07SB+SP
Unit Price inc. VAT £

Blade Tip Slide Plate - Pair - Stainless Steel

To suit 21mm high Aluminium rail - 7 1/4" gauge.

For 50mm wide x 25mm deep (or larger) sleepering

7 1/4"g. Pair of Blade Tip Plates - Stainless Steel. To suit 21mm high rail & 6.3mm dia rail screw.
Part No: 21MM07BTP
Unit Price inc. VAT £

Pairs of Check Rails - 5" gauge

For Standard Left/Right Points

1-3 1/2 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR35
Unit Price inc. VAT £21.50 per pair

1-4 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR40
Unit Price inc. VAT £22.50 per pair

1-5 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR50
Unit Price inc. VAT £25.50 per pair

1-6 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR60
Unit Price inc. VAT £26.50 per pair

1-7 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR70
Unit Price inc. VAT £33.00 per pair

1-8 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR80
Unit Price inc. VAT £36.00 per pair

For Symmetrical Wye Points

1-2 1/2 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR25Y
Unit Price inc. VAT £21.50 per pair

1-3 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR30Y
Unit Price inc. VAT £21.50 per pair

1-3 1/2 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR35Y
Unit Price inc. VAT £21.50 per pair

1-4 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR40Y
Unit Price inc. VAT £22.50 per pair

1-5 crossing angle. 5" gauge 21mm high Aluminium rail.
Part No: 21MMA05CR50Y
Unit Price inc. VAT £25.50 per pair

Pairs of Check Rails - 7 1/4" gauge

For Standard Left/Right Points

1-2 1/2 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR25
Unit Price inc. VAT £21.50 per pair

1-3 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR30
Unit Price inc. VAT £21.50 per pair

1-3 1/2 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR35
Unit Price inc. VAT £23.50 per pair

1-4 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR40
Unit Price inc. VAT £24.50 per pair

1-5 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR50
Unit Price inc. VAT £26.50 per pair

1-6 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR60
Unit Price inc. VAT £28.50 per pair

1-7 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR70
Unit Price inc. VAT £35.00 per pair

1-8 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR80
Unit Price inc. VAT £38.00 per pair

For Symmetrical Wye Points

1-2 1/2 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR25Y
Unit Price inc. VAT £21.50 per pair

1-3 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR30Y
Unit Price inc. VAT £21.50 per pair

1-3 1/2 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR35Y
Unit Price inc. VAT £23.50 per pair

1-4 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR40Y
Unit Price inc. VAT £24.50 per pair

1-5 crossing angle. 7 1/4" gauge 21mm high Aluminium rail.
Part No: 21MMA07CR50Y
Unit Price inc. VAT £26.50 per pair

Check Rail Spacers - Stainless Steel

5" gauge set of 4 for 21mm high rail. Plus 4 Stainless Steel M4 bolts and Nyloc nuts
Part No: 4XP21A05CRSP
Unit Price inc. VAT £3.00 per set

5" gauge set of 6 for 21mm high rail. Plus 6 Stainless Steel M4 bolts and Nyloc nuts
Part No: 6XP21A05CRSP
Unit Price inc. VAT £4.50 per set

7 1/4" g set of 4 for 21mm high rail. Plus 4 Stainless Steel M4 bolts and Nyloc nuts
Part No: 4XP21A07CRSP
Unit Price inc. VAT £3.50 per set

7 1/4" g set of 6 for 21mm high rail. Plus 6 Stainless Steel M4 bolts and Nyloc nuts
Part No: 6XP21A07CRSP
Unit Price inc. VAT £5.25 per set

16mm high & 21mm high Aluminum Rail Adapter Set

Utilising standard fishplates for each section but with a modified rail end.

Adapter rail set for 5" g OR 7 1/4" g
Part No: 16-21ADS2
Unit Price inc. VAT £22.00 per set

Adapter rail set for 5" g AND 7 1/4" g dual-gauge
Part No: 16-21ADS3
Unit Price inc. VAT £33.00 per set
